Automatic Car Wash Project Planning
PRODUCT PARAMETERS
Description
| Vehicle and bay Passenger cars ≤5.5–5.9 m long; bay 7.6–8.5 × 4.0–4.5 × 3.35–3.8 m. |
| Whole-site allowance 150–300 m² for one bay including queuing/circulation; shape may change the requirement. |
| Queue starting point 3–5 passenger cars; roughly 18–30 m linear queue length. |
| Installed equipment load 25–45 kW including selected dryers; treatment and lighting separately added. |
| Capacity assumption 6–10 vehicles/h site budget; full program 6–8 min, with entry/exit allowance. |
| Freshwater demand without reuse 100–200 L/vehicle; 0.6–2.0 m³/h at 6–10 vehicles/h. |
| Storage and treatment 1–2 m³ supply tank; optional 3–5 m³/h recycling equipment initial class. |
| Utility room 6–10 m² preliminary allowance, with access to tanks and pumps. |
| Power supply options 380 V / 3-phase / 50 Hz baseline; 400–415 V or 60 Hz only with matched motors and controls. |
| Site planning conditions 5–40 °C assumed, frost-free; allow 800–1000 mm maintenance access. |
| Notice Machine wash-cycle time is not the same as site throughput. Verify all installed equipment and utilities together. Profitability, staffing savings and local approval are not established by the equipment package alone. |
| Parameter status Reference values only. Confirm the actual model, operating conditions and supply scope before ordering or publishing rated specifications. |
vide customized requirements
FAQs
1. What types of car wash equipment do you offer?
Weile offers automatic car wash systems, bus and truck wash systems, heavy-duty vehicle wash equipment, self-service car wash equipment, and related accessories. Options include gantry, enclosed tunnel, and touchless wash configurations. The right equipment depends on your vehicles, site conditions, and cleaning requirements.
2. How is the car wash equipment shipped?
Shipping is arranged according to the equipment dimensions and destination. Large car wash systems generally require sea freight, with container type and loading arrangements confirmed before shipment. Suitable spare parts may be sent by air freight or international courier. Freight costs, delivery terms, and customs responsibilities are confirmed in the quotation or contract.
3. Can the car wash system be customized to our requirements?
Yes. We can assess customization based on vehicle dimensions, site layout, cleaning zones, water supply, and local electrical requirements. Enclosed layouts and water recycling options can also be reviewed. For open-top trucks, the wash configuration focuses on sides and underbody, without overhead spraying into the cargo body. Final specifications are confirmed after technical review.
4. What is the ordering process?
Send us your vehicle details, site dimensions, destination country, and cleaning requirements. We then review the application and provide a proposed configuration and quotation. After both parties confirm the specifications, supply scope, payment terms, and delivery schedule, the order proceeds to production, inspection, and shipment. Installation and commissioning arrangements are agreed before delivery.
5. What after-sales support do you provide?
After-sales support covers operating guidance, routine maintenance guidance, remote troubleshooting, and spare-parts assistance for the supplied car wash equipment. Installation, commissioning, operator training, and on-site service can be arranged according to the agreed service scope. Warranty coverage, service charges, and travel costs are specified in the contract.
